Brand Name : | WINTAI |
Model Number : | FS360-S |
Price : | To be discussed |
Payment Terms : | L/C,D/A,D/P,T/T |
Supply Ability : | 100 sets/mornth |
Delivery Time : | 15-25 days |
Special Feature
Users can set chemical consumption automatically on touch screen according to the dirty degree of vehicles.
Wasing Mode
Fine Mode (5 minutes/car): start--chassis/wheel rim
flushing--Colorful high foam detergent spraying--High Pressure Car
Body Flushing--
Low foam detergent spraying--High pressure car body flushing--Wax
Spraying--Wax Rain--Drying
Fast Mode (2 minutes/car): start--chassis/wheel rim
flushing--Colorful high foam detergent spraying--High Pressure Car
Body Flushing--
Wax Spraying--Wax Rain--Drying
Model | FS360-S |
Three phase electricity/overall power | 380V/50Kw |
Power requirements(kw) | 380V/33Kw/50Hz |
Installation requirements(mm) | 7000*3800*3200 |
Maximum car wash size(mm) | 5600*2500*2050 |
Hanging rail length (mm) | 7000mm |
Overall weight/volume | 2200kg/12m³ |
360 degree rotary flushing | 304 stainless steel rotating arm |
Main water pump motor/power (kW) | 380V/15kw |
Fan motor/power (kW) | 5.5kw*6 |
High pressure flushing pressure | 60-100kg |
Rinse the car body once | 2 8 S |
Liquid consumption(ml) | 20-50ml |
Power consumption(kWh) | 0.3-0.8/per |
Water consumption(L) | 80-150L |
![]() |
